| ชื่อแบรนด์: | GENY |
| เลขรุ่น: | YC-1893D |
| ขั้นต่ำ: | 1 ชิ้น |
| ราคา: | ต่อรองได้ |
| เงื่อนไขการจ่ายเงิน: | l/c, t/t, d/p |
| ความสามารถในการจําหน่าย: | 100/ปี |
| Parameter | Specification |
|---|---|
| Voltage | 3x230 / 400 V ±10%, 50 / 60 Hz ±2 Hz |
| Frequency | 50 Hz ±15% |
| Power capacity | > 6 kVA |
| Power efficient (at full load) | ≥85% |
| Ambient temperature | -10 °C -- +40 °C |
| Relative humidity | 35% - 85% |
| Test voltage output (Phase-Neutral) | 3x(24 - 300 V) |
| Power of the voltage output | 3×1500VA |
| Resolution | Better than 0.01% of full scale value of range |
| Setting accuracy | Better than 0.05% at the final range value |
| Stability | Better than 0.005%/h (integration time 150 s) |
| Load regulation from 0-max. load | < 0.01% |
| Distortion factor | < 0.3% for linear resistance load |
| Harmonics | 2nd - 41st free programmable |
| Test current output | 1 mA - 120 A |
| Power of the current output | 3×2000VA |
| Resolution | Better than 0.01% of full scale value of range |
| Setting accuracy | Better than 0.05% at the final range value |
| Stability | Better than 0.005%/h (integration time 150 s) |
| Load regulation from 0-max. load | < 0.01% |
| Distortion factor | < 0.3% for linear resistance load |
| Harmonics | 2nd - 41st free programmable |
| Range | 0 -- 360° |
| Resolution | 0.01° |
| Setting accuracy | 0.1° |
| Range | 45 Hz - 65 Hz |
| Resolution | 0.01 Hz |
